WEDOLiT Products for Pipe Expansion
WEDOLiT EXPANDER OILS - THE NEXT GENERATION
WEDOLIT is trusted by leading pipe manufacturers and offers excellent performance tailored to the needs of those producing thick-walled, large-diameter pipes for demanding applications.
NEXT-GEN EXPANDER OILS WITH EASY SPLITTING TECHNOLOGY:
Highest expansion performance with reduced temperature peaks
Easy post-process cleaning
Superior slip-stick avoidance
Enhanced corrosion protection
Stable hydraulic pressures
33% fewer splitting additives required
Lower chemical usage and costs
Optimized water recovery and reuse
Reduced fresh water and splitting agent consumption
Excellent lubrication with minimal application
WEDOLiT EP PRODUCTS
EXPANSION FLUID
|
PRODUCT |
TECHNOLOGY |
FEATURES |
TYPE |
VISCOSITY @40 °C |
PUMPABILITY AT LOW TEMPERATURE |
EP ADDITIVES |
4 BALL N |
WASHABILITY In s |
|---|---|---|---|---|---|---|---|---|
|
Expansion fluid |
• Very high film stability; good adhesion; easily removable by water (spontaneous emulsification). |
Ester |
>380 |
+++ |
++ |
2700 |
30 |
|
|
WEDOLIT EP 430-ES |
Easy Splitting Technology |
• Excellent oil-water separation in expansion operations. |
Ester/ MO |
>380 |
++ |
+ |
3200 |
20 |
|
WEDOLIT EP 435-E |
Expansion fluid |
• Very high film stability, good adhesion on smooth surfaces, wear protection; easily removable with water. |
Ester |
>380 |
+++ |
++ |
3400 |
30 |
|
WEDOLIT EP 438 E |
Expansion fluid |
• Excellent stability at temperature > 40 degrees; good adhesion on smooth surfaces, wear protection • Very good washability |
Ester |
>380 |
+++ |
+ |
3600 |
25 |
|
WEDOLIT EP 540 |
Expansion fluid |
• Very high film stability, good adhesion; easily removable by water (spontaneous emulsification) • Prevents stick-slip via polar additives |
Ester |
>380 |
+ |
++ |
4400 |
25 |
|
WEDOLIT EP 540-CM |
Expansion fluid |
• Very high film stability; good adhesion; easily removable with water. |
MO |
>380 |
++ |
++ |
4200 |
25 |
|
WEDOLIT EP 540-ES |
Easy Splitting Technology |
• Very high film stability; strong wear protection; easily removable with water; lower splitting-media consumption. • Excellent oil-water separation in expansion operations. |
Ester |
>380 |
++ |
++ |
4200 |
20 |
|
WEDOLIT EP 545-E |
Expansion fluid |
• Likely similar high-viscosity expander oil for pipe expansion with high film stability and wear protection. |
Ester/ MO |
>380 |
+++ |
++ |
4200 |
30 |
|
WEDOLIT EP 760 |
Expansion fluid |
• Very high film stability, good adhesion; easily removable by water • Prevents stick-slip via polar additives |
Ester/ MO |
>380 |
+ |
++ |
6000 |
30 |
|
WEDOLIT EP 760-E |
Expansion fluid |
• High film stability; good adhesion; supports water-removal cleaning (emulsification). |
Ester |
>380 |
+++ |
+++ |
6000 |
30 |
|
WEDOLIT EP 760-ES |
Easy Splitting Technology |
• Excellent oil-water separation in expansion operations. • Very high film stability; strong adhesion; very efficient with minimal splitting media needed. |
Ester/ MO |
>380 |
++ |
+++ |
6000 |
25 |
|
WEDOLIT EP 760 CM |
Expansion fluid |
• High film strength and wear protection; designed for easy cleaning/emulsification. |
Ester/ MO |
>380 |
++ |
++ |
6000 |
30 |
|
WEDOLIT EP 1090 |
Expansion fluid concentrate |
• Very high film stability even under high pressure. • Can be used undiluted; prevents stick-slip via high polar additive content. |
Ester/ MO |
>380 |
+ |
+ |
8500 |
30 |
